4 Basic Functions
l Plate: zinc oxide plate paper, water soluble paper and parchment paper used for mini offset print press; color cardboard for packing cover and projection film
l Copy: multiple copy at one time scan by laser imaging, automatic paper selection, automatic zoom, automatic density and so on
l Print:GDI included, less cost than profession printer
l Scan: scan paper document into e-document, diversify office work by sharing and applying data
| plate --specifications |
| paper size |
A3, B4, maximum width:320cm length:500cm |
paper type |
zinc oxide plate paper、water soluable paper、polyester paper、parchment paper color cardboard paper |
| gripper edge setting |
digital multi file location, size:0-50mm |
plate-copy switch |
one key switch |
| copy--specifications |
| resolution ratio |
600dpi x 600dpi/256 grade |
| memory capacity |
32MB (maximum 160MB by options ) |
| manuscript type |
paper/book/3D object(no more than 3.0kg) |
| size |
A3,B4,A4,A4 horizontal,B5,B5 horizontal,A5,A5 horizontal,postcard special paper size:max. 297*432mm,min.90*140mm |
| paper type |
common paper, recycled paper, thick paper, OHP, postcard paper, label paper, envelop |
| preheating time |
within 30 seconds (room temperature) |
| speed |
18 sheets/minute(B5), 12 sheets/minutes(A43) |
| output time for first copy |
within 7s(A4 horizontal) *manuscript table scanning and by 1st paper tray |
| paper thickness |
copy paper60-157g/m2, plate paper 60-500g/m2 |
| continuous copy sheets |
1-99 sheets |
| interface |
USB2.0 |
| power |
220-240V, 5.5A (50/60Hz) |
| maximum power consumption |
1.05kw |
| size(length*width*height) |
599*620*520mm(include cover plate) |
| area (length*width) |
599*620mm |
| weight |
about 39kg |
| print--specifications |
| GDI Driver |
built-in, TCP/IP |
| continious printing speed |
22sheets/min. (B5:300*300dpi) 16sheets/min. (A4:600*600dpi) |
|
| resolution ratio |
300*300dpi, 600*600dpi |
| OS supported |
windows98//me/2000(SP14 more)/XP(SP2 more)/server2003 |
|
| interface |
USB2.0 |
| network print |
options: Ethernet 100 Base-TX/10Base-T |
|
| scan--specifications |
| method |
local TWAIN black and white scanning |
| max. manuscript size for scanning |
A3 |
| resolution ratio |
150*150dpi, 300*300dpi, 600*600dpi |
| interface |
USB2.0 |
| OS supported |
windows98/ME/2000/XP/Server2003 |
| Driver |
TWAIN |
|
| Specifications for AP320II |
| Model |
AP320Ⅱ |
|
| function |
plate,copy,print,scan |
|
| extra black |
------ |
| energy saving |
------ |
| on the version |
------ |
| longevity |
------ |
| preheat time |
within 40s |
| effective breadth |
effective text breadth A3 |
| （297mm×420mm） |
| fixation |
no fixation |
| buy Solid version machine for fixation |
| retouching method |
by cleaning with cotton ball |
| or scan into e-document for correction |
| switcher |
"plate and copy" key |
| mirror image |
WPS、Graphics9 |
| print |
GDI(included)，PCL(purchase on selection) |
| scan |
TWAIN / WIA |
| internal memory |
32MB(included) :160MB(or equiped on selection ) |
| dot per inch |
600dpi×600dpi，color gradation:256 |
| printing plate |
320mm (width)、600mm (length) |
| size |
（vertical plate、horizontal plate） |
| rate |
16 sheets/minute（A4 horizontal） |
| gripper edge |
0-50mm |
| application paper |
zinc oxide plate paper、water soluable paper、polyester paper、chrome paper,alabaser paper,parchment paper |
| film film |
| plate thickness |
60-500g/m2 |
| zoom |
25～400%（1%unit） |
| volume |
599×620×520mm |
| weight |
about 39kg |
| power consumption |
AC220-240V 1.05kW |
|
|
